SMA公头转TNC母头电缆组件

TNC 反极性母头转SMA 反极性公头电缆组件，同轴电缆53欧姆 RG55

产品编号PE3W07647
Reverse Polarity TNC Female to Reverse Polarity SMA Male Cable Using 53 Ohm RG55 Coax

图片：  Reverse Polarity TNC Female to Reverse Polarity SMA Male Cable Using 53 Ohm RG55 Coax high resolution
查看大图


点击这里PE3W07647数据
请输入长度来计算价格
标准长度
12 in.24 in.36 in.48 in.60 in.50 cm.100 cm.150 cm.200 cm.
长度定制
当天发货
长度：
*长度四舍五入到最近的英寸或厘米。为了获得精确的长度，请致电400 928 5100。

Click on the below images to access KitBOM product pages:


PE4685RG55B/UPE4767KitBOM Datasheet

Key Specifications (Click on Data Sheet Above for Additional Details).
Connector Series 1TNC
Connector Gender 1Female
Connector Polarity 1Reverse Polarity
Connector Angle 1Straight
Connector Mount Method 1None
Connector Impedance 150 Ohm
Connector Series 2SMA
Connector Gender 2Male
Connector Polarity 2Reverse Polarity
Connector Angle 2Straight
Connector Mount Method 2None
Connector Impedance 250 Ohm
RF Cable Part NumberRG55B/U
RF Cable TypeRG55
RF Cable Impedance53 Ohm


Reverse Polarity TNC Female to Reverse Polarity SMA Male Cable Using 53 Ohm RG55 Coax

PE3W07647 is a reverse polarity TNC female to reverse polarity SMA male cable using RG55 coax. This Pasternack reverse polarity TNC female to reverse polarity SMA male cable assembly uses a 50 Ohm TNC for connector 1 and a 50 Ohm SMA for connector 2.

Our reverse polarity female TNC to reverse polarity male SMA cable assembly uses a flexible cable type that is 53 Ohm. Pasternack PE3W07647 TNC reverse polarity female to SMA reverse polarity male cable assembly is constructed with RG55 coax.
